Aseptic necrosis of the maxilla on embolized patient: a challenger condition

Aseptic maxillary necrosis is a complication that occurs when there is a reduction or interruption of vascularization in a given region, resulting in the loss of the affected tissues, which may involve only soft or hard tissues. This complication is not caused by an infectious agent, and the vascular supply can be interrupted by factors such as trauma (surgical or not surgical), medication use, radiation and arterial embolization (1-3).

Its occurrence ends up leading to an aesthetic and masticatory deficiency, especially in the case of young patients like the one in this report, who, at the age of 17, presented aseptic necrosis of the maxilla after osteotomy to remove a nasopharynx tumor. Because it is a patient in good general state of health and a non-smoker, it was hypothesized that the occurrence of this complication is associated to the surgical trauma and the performance of embolization of the maxillary arteries prior to surgery.

Arterial embolization is a procedure where biocompatible materials are arranged in such a way as to occlude arteries or arterioles, which can be performed for different purposes, such as causing tumor necrosis, stopping a hemorrhage, treating pseudoaneurysm or even facilitating the surgical removal of hypervascularized tumors (4), which was the purpose of its use in the present report. The material used to embolization in the present case was microparticles, but there are other options as acrylic adhesive and gelling solutions. Therefore, the decision is according to the clinical application and the expected effect (5,6).

Given the need for removal of a benign tumor located in the nasopharynx, the patient underwent bilateral maxillary artery embolization the day before resection surgery. In the immediate postoperative period, a slight ischemia was observed in the anterior region of the maxilla, which progressed, and at 6 months of follow-up, an extensive necrotic area in the anterior region of the maxilla was seen, involving mucosa, teeth, alveolar process and anterior portion of the hard palate (Figure 1). There were no signs of improvement even after adjuvant therapy with low-power laser (with red, continuous wavelength, power of 5 and 150 mW/cm²) and Tocopherol^® prescription.

Figure 1 Angiography of the right (A) and left (B) external carotid arteries before embolization. Necrotic area between canines, with involvement of the alveolar process (C). Right (D) and left (E) angiography after embolization, showing reduced vascularization in the region of the maxillary arteries. Immediate rehabilitation with removable prosthesis (F).

Although embolization is associated with cases of skin necrosis, amaurosis, peripheral facial paralysis and necrosis of the oral mucosa, maxillary necrosis after maxillary artery embolization has been little reported (7,8). The rarity of this occurrence is probably related to the rich vascular supply of the anterior region in the maxilla and palate, which is guaranteed by the branches of the external carotid artery (2). However, some vascular conditions were correlated with the risk of occurrence of aseptic necrosis when maxillary artery embolization, of which smoking, diabetes and poor oral hygiene can be cited (8), which differs from what was observed in this case, where such complication reached a patient who did not have these risk factors. Some precautions during embolization may reduce the chances of this complication occurring, it is important to use thin microcatheters, not to perform forced injection of particles, avoid branches with potentially dangerous anastomoses and pay attention to the size of the selected particle (7).

Besides embolization, another important factor is the management of the tissues during surgery, because improper handling can rupture the vessels responsible for the remaining vascular supply, as well as causing excessive injury, which will hinder the repair. Tumor lesions, such as those in the present case, are often treated more aggressively and can cause major damage to adjacent tissues (9).

Complementary therapies, such as low-level laser therapy and administration of vitamin E (Tocopherol^®), have demonstrated the potential to assist in tissue repair, as both optimize angiogenesis and osteogenesis. However, as seen in the present case, these auxiliary therapeutic modalities are not always sufficient to superimpose tissue damage in conditions of critical vascular decrease, such as that which may occur after the complication of an embolization (10,11).

Once this complication was present, as a therapeutic measure it was decided to resect the entire necrotic area, including the teeth and a fixation miniplate, located in the canine pillar region, which was compromised. We opted for the use of a piezoelectric, considering that this type of surgical instrument reduces the occurrence of damage to adjacent tissues, such as nerve damage, in addition to reduce postoperative edema and providing a more precise and well defined cut compared to conventional saws (12). This was followed by the patient’s prosthetic rehabilitation, using a removable prosthesis.

It is concluded that, despite being little reported, aseptic necrosis of the maxilla can occur in conditions of injury to the associated vascular system, requiring embolization procedures to be well indicated and performed. In addition, the need for care during tissue manipulation in surgeries is reinforced, especially in those areas with reduced vascular support by embolization.
