Robot-assisted surgeries in oral and maxillofacial area: a narrative review on the present, advantages and its future

Introduction

Efforts have continued to be made toward minimally invasive surgery (MIS), with head and neck surgery requiring incisions which will leave long visible scars to be used to approach the lesion. However, due to the difficulty in ligation of neurovascular structures, visualization of surgical fields, and proximity of anatomical critical structures, only recently have there been significant advances in minimally invasive techniques as applied in oral and maxillofacial surgery (1,2).

A series of attempts to achieve MIS were made using endoscopy, but was not so easy to operate (3). Given that robotic surgical systems can address these shortcomings, the use of robots in head & neck and maxillofacial surgery has recently become more common.

In this regard, we have borrowed the form of a narrative review (4), which known as an unsystematic review and provides comprehensive narrative syntheses, regarding the information reported so far and our experience. Therefore, we present this article in accordance with the Narrative Review reporting checklist (available at https://fomm.amegroups.com/article/view/10.21037/fomm-21-25.rc).

Methods

This paper is written in the form of unsystematic narrative review that focuses on inter-literature arbitration and comparison. Research of articles was conducted using the keyword including “Robotic Surgical Procedures”, “Neck dissection”, “Oral surgery” from the 1980s onwards on the PubMed database (Table 1).

Discussion

First of all, it seems that the explanation for the narrative review should be added first (4). Narrative reviews are also known as unsystematic narrative reviews, which may provide critique of the literatures being reviewed, but are not essential (5). This format is close to an educational article to keep clinicians up to date with low-scientific level, and is far from the articles that should derive objective results or design specific studies (6-8). Therefore, we will elaborate on the latest views and our experiences in the form of a narrative review.

History

The use of robots in the medical field started with the use of needles in brain biopsies in 1985 (2,9). Introduced in 1994, the first generation robotic system AESOP (Automated Endoscopic System for Optimal Positioning) was often used in cardiac, urologic, and gynecologic surgeries although it suffered several deficiencies (10). The second generation ZEUS Robotic Surgical System was introduced in 2001 (11). If Zeus was for surgeons who were accustomed to laparoscope, the third generation da Vinci system (Intuitive Surgical Inc., Sunnyvale, CA, USA) lent itself more to open surgery, being first used for surgery in the head and neck region (cf. excision of a vallecular cyst in 2005) and receiving FDA approval in 2009 for use on T1 and T2 cancers (12).

Da Vinci, which remains the most recent surgical system, has now undergone several developments. The Da Vinci single-port (SP) platform enables a less invasive approach than multiple ports (13).

Advantages

Cosmesis

Unlike conventional approaches, which require 10–15 cm of transcervical lip split incision, robotic surgery using trans-axillary or retro-auricular approaches naturally yield better aesthetic results. Studies by Ji and Lee evaluating postoperative cosmesis of robotic surgery in the head and neck region using a scoring system noted superior results over conventional approaches (14,15).

Complications

By enabling a transoral or retroauricular approach even in cases requiring the transcervical approach, or mandibulotomy with lip split, robotic surgery can reduce functional damage and decrease blood loss based on criteria such as the number of transfusions or mean drain stay (16). The length of hospital stay, chyle leak, hematoma, nerve weakness, seroma, wound infections and wound drainage have been evaluated in order to compare the postoperative course of robot assisted surgeries with conventional ones. According to a meta-analysis by Sukato et al. (17), there was no difference in the morbidity of local complications between robotic and conventional groups, nor was there a statistically significant difference in length of hospital stay. In addition, the incision line distant from the surgical site has clear advantages during radiotherapy (Figure 1).

Figure 1 Comparison of postoperative scars. (A,B) Postoperative photograph of a patient who underwent neck dissection and forearm free flap reconstruction for tongue cancer. Note the visible scars. (C,D) Postoperative photograph of a patient who underwent robot-assisted neck dissection and robot-assisted forearm free flap harvesting. The neck scar is undetectable, and the forearm scar is restricted to the flap region, with no long incision scar following pedicle harvesting.

Minimal required medical staff

Only one surgeon and one or two nurses are required for surgeries which would normally require at least three surgeons and two nurses (2).

Oncologic safety

Since robotic surgery is relatively new and prospective randomized control trials are lacking (12), oncologic safety has not been fully evaluated. The concept of “lymph node yield” has emerged as a factor for evaluating the oncologic safety of robotic surgery because it becomes an important prognostic factor for survival within a limited follow-up time (18). In addition to the lymph node yield, the local recurrence rate also shows no statistically significant difference between the two groups in the oromaxillofacial region as well as in the case of neck dissection accompanying thyroidectomy (17).

Limitations

Lack of haptic feedback

It is impossible to feel the resistance, strength, pulse of the tissues directly through the currently available surgical robots. Even though visual cues can compensate for the lack of haptic feedback, multiple capsule breakages have been reported in the case of capsulated tumor such as pleomorphic adenomas due to the lack of haptic feedback during grasping and dissecting (11). Future developments will likely provide haptic feedback to reduce the neoplasm rupture and operation time, while a number of surgical experiences may enable such improvement even without haptic feedback (19).

Complexity & cost

The docking process and surgery itself requires a specific amount of time and training to warrant fluency (20). Structured training programs are provided to achieve such expertise. Thus, robotic surgery is not covered by the national health insurance system, patients have to pay considerable costs. Nevertheless, insurance coverage differs among countries for such a procedure, which is usually more costly than conventional surgeries.

Other than this, tongue edema due to similar or slightly longer operation times compared to conventional methods (21), difficulty of access due to limit to the space between the skin and the subplatysmal space in the head and neck (22,23).

Clinical applications

Removal of a tumor

Tumors in the head and neck are often resected, including structures essential for speaking and swallowing, such as pharynx and larynx. However, we can see from a number of examples that robots approach normal tissues with minimal invasion, thus preserving pronunciation and swallowing function as much as possible (12,24,25). Similarly, several studies have reported significantly better functional recovery using robots as measured by the following criteria: proportion of negative operative margin, recurrence-free & disease-free survival, overall survival, hemorrhage risk, and gastrotomy or tracheo tube insertion rate (26-30). The quality of life of patients undergoing transoral robotic surgery (TORS) decreased significantly for 3–6 months after surgery, then returned to preoperative condition a year later (31). Furthermore, Park et al. have shown that robotic surgery results in significantly less postoperative pain and anxiety as well as faster restoration of appetite (29).

Removing a tumor from parapharyngeal space requires access through the neck, often combined with mandibulotomy, resulting in noticeable scars and, in some cases, mandibulotomy-related complications. TORS has shown advantages over traditional methods in terms of the incidence of complications and postoperative bleeding (21,22). Lee et al. showed that the TORS group had shorter operation times, more rapid recovery of swallowing, and shorter hospital stays than the conventional group (32). Although the transcervical approach is inevitably required in the case of, for example, submandibular gland excisions, an “invisible scar” is achievable using a retroauricular approach or modified face lift incision. In addition to this aesthetic benefit, robotic surgery offers a technical advantage: whereas open surgeries require an inconvenient change of instruments to use a neurostimulator, a robot with an attached neurostimulator emits a warning sound when the robot arm touches a nerve.

Neck dissection

The first neck dissection using a robot, through the transaxillary approach, was reported by Kang et al. (33). Kang et al. also reported that long, visible scars and decreased muscle performance caused by dissection to deep areas were preventable. However, due to the difficulty of dissecting Levels I and IIB with transaxillary approach, Lee et al. developed and reported the retroauricular, or face-lift, approach (34). Though robot-assisted neck dissection obviously takes longer than open surgery, intra-operative bleeding, nodal recurrence, postoperative drainage and hospital stay are similar to those of open surgeries, and patients are quite satisfied with postoperative aesthetics (16,34).

Cleft palate

Robotic surgery to cleft lip and palate is still in its early stages. Nadjmi reported that muscle sling reconstruction took an average of 9.5 months (n=10), much longer than with conventional surgeries, but with significantly shorter hospital stay and functional recovery (35). Nadjmi attributes these results to the precision of robotic dissection, which reduces damage to vascularization and innervation of muscles.

Microvascular reconstruction using free flaps

Even with retroauricular approaches or partial extension to the preauricular incisions, large flaps such as fibular osteocutaneous flaps can be positioned and done with anastomoses (Figure 2), resulting in more aesthetic results than with conventional surgical procedures that require transcervical approaches (Figure 3).

Figure 2 The vision of the vascular anastomosis is secured through facelift incisions.

Figure 3 Postoperative photographs of a patient who underwent selective neck dissection (levels I, II, III), segmental resection of mandible and reconstruction with fibula osteocutaneous free flap via intraoral & retroarticular approach. The surgery has left no visible traces. This image is published with the patient’s consent.

Scar reduction is imperative, not only in flap insetting, but also in flap harvesting, and is feasible with robots (36,37). Using robots to harvest radial forearm free flaps can provide superior postoperative outcome in terms of both aesthetics and complications (Figure 1). Robot-assisted maxillofacial surgery with free flap reconstruction is reported to yield no statistically significant difference compared to conventional approaches in the morbidity of postop infection, drain time and ICU or hospital stay (16).

Conclusions & perspectives

Currently the robot cannot perform surgeries involving manipulation of the bone, such as osteotomy or ostectomy. Advances enabling osteotomies may lead to the development and widespread use of robots in the field of craniomaxillofacial surgeries, which frequently involve manipulation of bones. Flexibility and miniaturization of multiports is also needed.

In addition to technical considerations, it is expected that artificial intelligence (AI) and imaging technology will be commonly incorporated into robotic surgical systems, further enhancing their utility.

Image-guided surgeries, performed after injecting ICG dye into blood vessels, have been used to delineate the cancer margin in urology, hepatobiliary, and colorectal surgery, as well as to explore sentinel nodes; there are also reports of robots being used in monitoring the flap pedicle (38-40). Da Vinci’s camera has a built-in Near Infrared (NIR) system which can be activated simply by finger trigger.

We expect improved interaction between robot and environment for simple surgical tasks such as suturing; recognizing the surgeon’s gaze, hand gestures, or voice; and making the robot do the work of a nurse, such as tool changes. Furthermore, visual model-based reinforcement learning may lead to robotic execution of complex tasks such as surgical procedures (41). Finally, by utilizing a large database of surgical procedures, the deep learning process will not only reduce unexpected situations during surgery, but also avoid dangerous situations within closed spaces (e.g., arthroplasty) by establishing safe boundaries (2).
